A groundbreaking innovation that redefines traditional freezer spacer handling with a fast and highly functional machine.
Freezer Spacer Removal and Insertion System
L-Shape Splitter
Get in touch with our experts
Model:
Semi Automatic System
Capacity:
Up to 2870 lbs
Pallet size:
Up to 40″ x 48″
Loading:
At floor level
The L Shape Splitter is a stationary machine specifically designed to assist the operator in the insertion and removal of freezer spacers.
It represents a revolution and an innovative solution for all those who manage freezer spacers, as they no longer need to manually depalletize the entire load to insert or remove the spacers.
This ergonomic solution, is the only machine on the market capable of assisting the operator with the insertion of freezer spacers. Due to its conveyors and a small robot positioned on the machine, it allows each layer to be separated to one another and insert the freezer spacers.
The L Shape is an exclusive patent of Toppy.
Toppy’s patented solution;
Insertion and removal of freezer spacers;
Handles up to 30 pallets per hour;
Features at a Glance
It assists the operator with both the insertion and removal of freezer spacers. It’s the only machine on the market capable of performing both operations.
Smooth and precise operation is possible thanks to the user-friendly controls, allowing operators of all skill levels to be productive with minimal practice.
Designed from the ground up by the CEO and Production Director of the Toppy Group, it has been rigorously tested and refined over the years. Today, it’s one of the best-selling machines based on demand.
One of our greatest strengths: 100% Made in Italy, crafted in Bologna at our headquarters with top-quality Italian components. These ensure our machines are built to last, making us global industry leaders!
It is also designed to assist the operator in exchanging pallets, whether from the destination or the original pallet.
Our in-house engineering department is able to develop a customized machine layout, adapting it perfectly to the available space at the customer’s site. The design approach takes into account not only the dimensions of the area but also the specific needs and requirements of the customer, ensuring a tailored solution that optimizes the efficiency and functionality of the system.
Cycle Overview – Insertion of Freezer Spacers (1)
The operator inserts the load onto the machine’s platform, closes the upper compactor, and tilts the load up to 95°.”
1
At this point, the operator opens the upper compactor with the buttons detailed in the image
2
Once the upper compactor is slightly opened, the load can be shifted to the left since the motor controls all the rollers to the left of its position
3
Once all the freezer spacers are inserted, the operator closes the upper compactor
4
Once the insertion operation is finished, the operator returns the load back to its vertical position and the entire operation is completed.
5
Cycle Overview – Removal of Freezer Spacers (2)
The operator inserts the load onto the machine’s platform, closes the upper compactor, and tilts the load up to 95°.”
1
At this point, the operator opens the upper compactor with the buttons detailed in the image
2
Once the upper compactor is slightly opened, the load can be shifted to the left since the motor controls all the rollers to the left of its position
3
Once all the freezer spacers are removed, the operator closes the upper compactor
4
Once the removal operation is finished, the operator returns the load back to its vertical position.
5
Contact our Experts for Details
Get in touch with our experts
Overview of L-Shape Splitter equipped w /conveyor
Frequently Asked Questions
How can I tell if this machine is right for my business?
This solution is designed for customers who need to change pallets and simultaneously add o remove freezer spacers.
However, if you’re not sure which machine is right for you, don’t worry.
Our product range includes a variety of models, and to identify the best solution for your needs, we begin by analyzing your products, the pallets you use, and most importantly, how many pallet changes you make per hour. With this information, we can quickly recommend the most efficient solution for your specific requirements.
What about after-sales service?
It’s one of our strengths. Our after-sales team is available 24/7.
For both mobile and fixed machines, we always offer an emergency spare parts kit. If additional parts are needed, we have a fully stocked inventory in Davie, Miami, and can ship what’s necessary within a few business days. In the case of a machine needing a repair, we have a team of talented technicians ready to be deployed. For automated solutions, we always schedule routine maintenance after the purchase to ensure everything is running smoothly.
How soon can I see ROI with a pallet changer?
The return is practically immediate from an ergonomic perspective. Just imagine – no more physical strain on operators, no injuries, and the pallet changing process is significantly sped up with automation.
Why Top Industries Inc?
Top Industries Inc offers the most advanced technologies not only in the USA but worldwide.
Our parent company and Italian manufacturer, Toppy, is the world-leading company for state-of-the-art pallet exchanging solutions. They have a great deal of experience since being established in 1978 and supplying over 20,000 units in more than 147 countries!
Can the machines be customized for specific application?
Customization and tailoring machine / system is our specialty. When it comes to fully automated lines, we always provide customized solutions for each unique case, as every production flow involves different needs.
